BLACKFRIARS BRIDGE Blackfriars Bridge, London Leica HDS4500 Leica ScanStation Total Station GRP5000 Rail Trolley 3D CAD Model Registered Point Clouds TruViews Railway Surveying is not just about tracks as we proved on the Thameslink Project. The Thameslink Programme was a huge project of track and infrastructure [...]
HAMMERSMITH BRIDGE Hammersmith, London Leica ScanStation P40 Total Station RECAP, PTS & E57 Colour Point Cloud Files Wireframe CAD Model Introduction Hammersmith Bridge was constructed circa 1887 and is a Grade 2* listed structure. It crosses the River Thames and consists of [...]
DERBY STATION REMODELLING Derby Railway Station, UK Leica P40 Scanner Total Station 3D CAD Model As part of the Derby Station remodelling programme there was a requirement for an as-built of a new footbridge. The bridge was scanned both externally and internally using a Leica P40 scanner and [...]
Gospel Oak - Barking Electricification Gosepl Oak - Barking, UK Air Survey Leica P40 Scanner Total Station GPS GRP Rail Trolley 3D Surface Model Gauging Data Aerial Photography This was a Network Rail project to electrify the line between Gospel Oak and Barking, a distance of some 20km, with 5km being [...]
Panmon Project - Cheddington Cheddington, Buckinghamshire, UK Leica P40 Scanner 3D Surface Model The Panmon Programme was a Network Rail project to mount special cameras on selected gantry’s to monitor wear on the contact wire. This information can then be transmitted back over time to an office for analysis. [...]
Oxford Corridor Project Oxford, UK Leica HDS 6200 GRP Rail Trolley Total Station GPS 3D CAD Models Gauging Data POD Files TruView The Oxford Corridor is a site of extensive capacity and performance investment in the railway network. In 2014 ABA was contracted by TATA Steel to survey [...]
LONDON OLYMPIC STADIUM Stratford, London, UK Leica HDS 6100 Wireframe 3D CAD Model In 2009 ABA Surveying was asked by the Team Stadium Consortium to provide accurate as-built models of the upper tier roof structure steelwork at the Olympic Stadium during the construction process. Accurate as-builts were required [...]
